This is a really quick and easy build that won't break the bank. Perfect for a beginner! The headboard is designed to fit with an existing twin bed frame. It would be great for either a boys or girls room. Since the headboard is so basic, you could easily add extra moulding or details to customize.

Difficulty moderate

Tools

Kreg Tools

Other Tools

  • Miter Saw
    Miter Saw
  • Tape Measure
    Tape Measure
  • Impact Driver
    Impact Driver
  • Nail Gun
    Nail Gun
  • Sander
    Sander

Materials

Wood Products

  • 1 Board , 2x4 , 96"
  • 1 Board , 1x4 , 72"
  • 2 Board , 1x2 , 96"
  • 1 Plywood , 1/4" Thick , Half Sheet

Hardware & Supplies

  • 50 1" pocket hole screws
  • 50 Finish nails
See All Tools & Materials

Cut List & Parts

  • 1 Plywood backing , 30 1/2" x 32" x 1/4"
  • 2 Bed posts , 45 1/2" 2x4
  • 1 Top rail , 39" 1x2
  • 4 Vertical slats , 23 1/2" 1x2
  • 2 Horizontal rails , 32" 1x4
twin-headboard-dimensions
twin-board-and-batten-headboard
See Full Cut List & Parts

Directions

  • Prepare Horizontal Rails

    Cut 2- 1x4 boards 32" long. Using a Kreg Jig, drill pocket holes in both ends of boards.

    Step 1

  • Prepare Vertical Rails

    Cut 5- 1x2 boards 23 1/2" long. Drill pocket holes in each end of all 5 boards.

    Step 2

  • Build Headboard Frame

    Space 1x2's 8 1/2" and 8 3/4" apart. Using 1" pocket hole screws and wood glue at the joints, attach the 1x2 boards to the 1x4's. Make sure your edge 1x2 boards are flush with the ends of the 1x4's.

    Step 3

  • Attach Legs

    Using 1" pocket hole screws and wood glue, attach the top and bottom 1x4's of your frame to the 45 1/2" 2x4 legs. The 1x4 should be centered on the 2x4, with 1/2" on each side. (see plans)

    Step 4

  • Completed Frame and Legs

    You should have a sturdy frame and legs now. Make sure everything is square and continue on to finish your piece.

    Step 5

  • Add backing

    Using finishing nails, attach a 32" x 30 1/2" 1/4" plywood to the back of your headboard. You may want to paint or stain the plywood ahead of time. This should cover up the pocket hole screws in the back.

    Step 6

  • Add top board

    To finish the headboard off, attach a 60" long 1x2 to the top of the headboard with brad nails.

    Step 7

  • Finish

    Fill any holes and edges with wood filler. Sand, and paint or stain the headboard.

    Step 8
